FCI
내압방폭 인디케이터 박스_ Control Station
Explosion-proof Indicator Panel
FCI Series for Hazardous Location
Protection Grade
Ex dⅡB+H2 T6 IP65 for Zone 1·2
Drawing
Standard Material
- Main Body : Cast Aluminium Alloy
- Cover : Cast Aluminium Alloy
- Indicate Glass : Heat Resistant Hard Glass
- Bolt & Washer : Stainless Steel
- Unit : PB, S/S, EM, PL(Red,Green,Yellow).BZ
Indicator, Frequency
- Tamb : -20℃ ≤ Ta ≤ +50℃
- Rated Voltage :
100-240Vac, 12-24Vdc 50/60Hz (FCI-*, FCI-2**, FCI-4****)
240V Below 50/60Hz (FCI-600), 230Vac, 24Vdc 50/60Hz (FCI-4030D)
460V,15A Below (FCI-3020, FCI-4060, FCI-5040, FCI-6030)
240V,30A Below (FCI-3040), 250V,15A Below (FCI-6040)
230Vac, 24Vdc 50/60Hz (FCI-4030D), 460V,60A Below (FCI-5040D)
Standard Color
- Munsell no. 7.5BG 6/1.5
If you want other color, contact us please.
Ordering Number
Model No. | Width(A) | Height(B) | Depth(C) | Mount(D) | Mount(E) | IP |
FCI-1* | 300 | 200 | 215 | 210 | 240 | X |
FCI-2** | 400 | 300 | 220 | 295 | 352 | X |
FCI-4**** | 400 | 500 | 230 | 455 | 400 | X |
FCI-600 | 220 | 250 | 160 | 260 | 170 | X |
FCI-3020 | 300 | 200 | 215 | 210 | 250 | IP65 |
FCI-3040 | 300 | 400 | 220 | 346 | 300 | IP65 |
FCI-4030 | 400 | 300 | 220 | 295 | 352 | IP65 |
FCI-5040 | 400 | 500 | 230 | 455 | 400 | IP65 |
FCI-5040D | 500 | 400 | 230 | 400 | 450 | IP65 |
FCI-6030 | 600 | 300 | 285 | 500 | 346 | IP65 |
FCI-6040 | 600 | 400 | 230 | 495 | 450 | IP65 |
